Lenovo ThinkSystem SR570 7Y03 3 year warranty DDR4 Intel Xeon 1U Rack Server SR570

Name: Lenovo ThinkSystem SR570 7Y03 3 year warranty DDR4 Intel Xeon 1U Rack Server SR570
Brand: Lenovo
Price: 2 USD

China Lenovo ThinkSystem SR570 7Y03 3 year warranty DDR4 Intel Xeon 1U Rack Server SR570 wholesale

Brand Name : Lenovo

Model Number : SR570

Place of Origin : China

Packaging Details : Original Packing

Supply Ability : 100 Carton/Cartons per Month

MOQ : 1 pieces

Price : $2,000.00 - $9,999.00/pieces

Payment Terms : T/T

Delivery Time : 1-2months

Products Status : Stock

Type : Rack

Processor Type : Intel Xeon

Memory : DDR4

Power Supply : 550w/750w

Warranty : 3 years

Port : Shenzhen/Beijing/HongKong

Contact Now

Details Images

Lenovo ThinkSystem SR570 7Y03 3 year warranty DDR4 Intel Xeon 1U Rack Server SR570

Machine types	7Y03 - 3 year warranty
Form factor	1U rack-mount
Processor	Up to two Intel Xeon Bronze, Silver, Gold, or Platinum Gen 2 processors of up to 150 W TDP: * Up to 24 cores (2.1 GHz core speeds). * Up to 3.8 GHz core speeds (4 cores). * Two UPI links up to 10.4 GT/s each. * Up to 35.75 MB cache. * Up to 2933 MHz memory speed. 1st Gen Intel Xeon processors are also supported.
Chipset	Intel C622
Memory	Up to 16 DIMM sockets (8 DIMMs per processor; 6 memory channels per processor with one DIMM per channel for four channels and two DIMMs per channel for two channels). Support for RDIMMs or LRDIMMs. Memory types cannot be intermixed. Memory speed up to 2933 MHz depending on the processor selected.
Drive Bays	* 4 LFF SATA Simple Swap drive bays * 4 LFF SAS/SATA hot-swap drive bays * 8 SFF SAS/SATA hot-swap drive bays * 10 SFF hot-swap drive bays: 6x 2.5" SAS/SATA & 4x 2.5" AnyBay
Internal storage capacity	* 2.5-inch drives: * 307.2TB using 10x 30.72TB 2.5-inch SAS/SATA SSDs * 32TB using 4x 8TB 2.5-inch NVMe SSDs * 24TB using 10x 2.4TB 2.5-inch HDDs * 3.5-inch drives: * 80TB using 4x 20TB 3.5-inch HDDs * 61.44TB using 4x 15.36TB 3.5-inch SAS/SATA SSDs
Storage controller	* 6 Gb Onboard SATA AHCI * 6 Gb Onboard SATA RAID (Intel RSTe) * 12 Gb SAS/SATA RAID adapters with up to 8GB flash-backed cache * 12 Gb SAS/SATA HBA (non-RAID) * Onboard PCIe NVMe (non-RAID, requires two processors) * 1610-4P NVMe Switch Adapter (non-RAID, only supported with one processor)
Power Supply	Up to two redundant hot-swap 550 W or 750 W (100 - 240 V) High Efficiency Platinum or 750 W (200 - 240 V) High Efficiency Titanium AC power supplies. HVDC support (PRC only).
Network Interface	* 2x Integrated 1 GbE RJ-45 ports (no 10/100 Mb support) * Onboard LOM slot for up to 4x 1/10 Gb Ethernet ports: * 2x 1 GbE RJ-45 ports (no 10/100 Mb support) * 2x 10 GbE RJ-45 ports (no 10/100 Mb support) * 2x 10 GbE SFP+ ports (no 10/100 Mb support) * Optional Mezzanine LOM (ML2) slot for dual-port 10 GbE cards with SFP+ or RJ-45 connectors. * 1x RJ-45 10/100/1000 Mb Ethernet systems management port.

Lenovo ThinkSystem SR570 7Y03 3 year warranty DDR4 Intel Xeon 1U Rack Server SR570 Images
